The SSD to trust
The newest edition to the world's best-selling SATA SSD series, the Samsung 860 EVO. Specially designed for mainstream PCs and laptops, with the latest V-NAND and a robust algorithm-based controller, this fast and reliable SSD comes in a wide range of compatible form factors and capacities.

Enhanced performance
Speeds are more consistent, even with heavy workloads and multi-tasks. The 860 EVO performs at sequential writes up to 520 MB/s with Intelligent TurboWrite technology, and sequential reads up to 550 MB/s. The TurboWrite buffer size is upgraded from 12 GB to 78 GB for faster file transfer.

Boosted endurance
Safely store and render large sized 4K videos and 3D data used by the latest applications, up to 8× higher TBW (Terabytes Written) than the previous 850 EVO. The latest V-NAND technology gives you up to 2,400 TBW, or is backed by a 5-year limited warranty.

Smart compatibility
Benefit from faster, more fluid communication with your host system. The refined ECC algorithm and a new MJX controller generate higher speeds, and the improved queued trim enhances Linux compatibility. Our advanced engineering makes the 860 EVO more compatible with your computing system.

Multi form factors
Whatever size your computer needs, there is an 860 EVO for you. Choose among the 2.5-inch size for desktop PCs and laptops, and the SATA-based M.2 (2280) or the mSATA for ultra-slim computing devices.

Samsung Magician – Management software
Samsung Magician software is designed to help you manage your SSD with a simple and intuitive user interface.

Firmware update
Get notifications when new firmware is released, and easily install updates for enhanced performance, stability, and compatibility.

Perf. benchmark
Check your SSD?s sequential and random read/write speeds, so you can maintain superb performance.

Data security
Protect data by selecting security options. The 860 EVO supports AES 256-bit hardware-based encryption and is compliant with TCG Opal and IEEE 1667.

Specifications

Capacity
1TB

Form Factor
2.5 inch

Interface
SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface

Dimension (WxHxD)
100 X 69.85 X 6.8 (mm)

Weight
Max 50.0 g Weight

NAND Type
Samsung V-NAND 3bit MLC

Controller
Samsung MJX Controller

Cache Memory
Samsung 512 MB Low Power DDR4 SDRAM

Special Feature

• TRIM Supported
• S.M.A.R.T Supported
• Auto Garbage Collection Algorithm
• AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
• World Wide Name supported
• Device Sleep Mode Support: Yes

Sequential Read
Up to 550 MB/s Sequential Read * Performance may vary based on system hardware & configuration

Sequential Write
Up to 520 MB/s Sequential Write * Performance may vary based on system hardware & configuration

Random Read (4KB, QD32)
Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration

Random Write (4KB, QD32)
Up to 90,000 IOPS Random Write * Performance may vary based on system hardware & configuration

Random Read (4KB, QD1)
Up to 10,000 IOPS Random Read * Performance may vary based on system hardware & configuration

Random Write (4KB, QD1)
Up to 42,000 IOPS Random Write * Performance may vary based on system hardware & configuration

Software
Magician Software for SSD management
