Product Features:
• True 10/100Mbps Network Connectivity
• Auto 10/100Mbps Speed Detection
• Backwards Compatible with USB 1.1
Specifications:
General
* USB Specification Version 2.0
* USB Specification Version 1.1
* USB Specification Version 1.0
* OHCI (Open Host Controller Interface)
* EHCI (Enhanced Host Controller Interface)
* IEEE 802.3 Ethernet
* IEEE 802.3u 100 BASE-T, TX and T4 compatible
* Supports suspended mode and remote wakeup
* Embedded 7K * 16 bit SRAM Buffer
* Supports full and half duplex in Fast Ethernet
Compatible Operating Systems
Microsoft Windows XP, Me, 2000, 98SE with USB Support
Ports/Connector
* One USB Type “A” connector
* One RJ-45 (10/100 Mbps Dual-Speed)
Wiring Topology: Tiered Star
Connectivity: Up to 127 devices by cascading multiple hubs
Diagnostic LED's
* Power/Link
* Tx/Rx traffic
Operating Temperature
0°C to 55°C
Storage Temperature
-20°C to 70°C, non-condensing
Humidity: 5% to 95%, non-condensing
Power Requirements: Bus Powered - 2.5 W, 0.5 A @ 3.3 VDC (+ or - .3 VDC )
Power Consumption: 150 mA @ 3.3 VDC
Compliance
* CE
* FCC Class B
* VCCI
* UL
