CPU:Pentium 4
Chipset:Intel 848P/ICH5
Socket:478
Form Factor:ATX (305mm x 218mm)
FSB:400/533/800/1000+(by overclocking) MHz
Memory:3*DDR266/333/400
Int. GFX:N
AGP:8X
PCI:5
USB:6 USB 2.0/1.1 Ports (4 ports by optional cable)
LAN:N
Sound:6 Channel AC97 Audio (Realtek ALC655)
South Bridge Speed :ATA100
RAID:N
Serial ATA:2 Serial ATA150 Channels
IEEE 1394:N
BIOS Mirror:N
Voice Genies:N

Features:

Intel Pentium®4 Processor (Northwood/Prescott)
Socket 478 with FSB 400/533/800/1000+(by overclocking) MHz
3 DDR266/333/400 Memory Sockets
6 Channel AC97 Audio
2 Serial ATA150 Channels
2 ATA100 Channels, up to 4 ATA 100 IDE Devices
6 USB 2.0/1.1 Ports (4 ports by optional cable)

Specifications:

Processor

Socket 478 Intel Pentium® 4 Processor (Northwood/Prescott)

FSB

400/533/800/1000+(by overclocking) MHz

Chipset

North Bridge : Intel 848P
South Bridge : Intel ICH5
AC97 Audio Codec : Realtek ALC655
I/O Chip: Winbond Smart I/O W83627HF

Memory

3 * DDR Sockets:
DDR400/333/DDR266 NON-ECC DDR SDRAM up to 2 GB
( DIMM1 uses 2 Banks/ DIMM2 & DIMM3 share 2 Banks )
Note 1: If the FSB of your CPU is 400 MHz, the memory speed supports only DDR 266.
Note 2: If the FSB of your CPU is 533 MHz, the memory speed supports DDR 266/333
Note 3: If the FSB of your CPU is 800 MHz, the memory speed supports DDR 266/333/400

Expansion Slots

1 x AGP(3.0) 8X slot (1.5V only)
5 x PCI slots (PCI 2.3 compliant)

IDE Connectors

2 ATA100/66 Channels, up to 4 ATA 66/100 IDE devices

Onboard I/O Connectors

1 x Floppy Connector
2 x USB 2.0/1.1 header (4 ports by optional cable)
1 x CD_IN header
1 x S/PDIF in/out header (S/PDIF in/out cable optional)
1 x CPU fan header ( 1 fan rotation detection function )
2 x System fan headers ( 2 fan rotation detection function )
2 x 5 pin system panel header (Intel spec)
1 x 3 pin Power LED header
1 x Front audio header (Intel spec)
1 x IrDA header
1 x Case Open detection header

I/O via Back Panel

PS/2 keyboard/mouse, 2 x USB(2.0/1.1),2 x Com(serial), 1 x Parallel, 1xLine-in/Line-out(Speaker Out)/MIC

Power

20-pin ATX power connector, 4-pin ATX 12V power connector

BIOS Feature

3Mb Flash EEPROM
Award BIOS with ACPI, DMI2.0, PnP, WfM2.0, Green Suspend to RAM (S3), Suspend to Disk (S4) Wake on keyboard/mouse, Wake on LAN/RTC Timer

Hardware Monitoring

3 FAN sensors, CPU/System voltages and temperature monitoring

Special Feature

Zero Jumper Design
Adjustable CPU frequency by 1 MHz increment, Adjustable Vcore, VAGP, VMemory for overclocking
Watch Dog Timer (auto-reset system when it can not handle overclock configurations)
AGP Protection ( The AGP Protection can ensure the AGP card voltage to be 1.5V, to protect the mainboard and the AGP card )

Certifications

FCC, CE, BSMI

Form Factor

ATX (305mm x 218mm)
