CPU:Pentium 4
Chipset:Intel 915P/ICH6
Socket:478
Form Factor:ATX (244 mm x 305 mm)
FSB:533/ 800 MHz
Memory:4*DDR333/400(Dual Channel DDR400)
Int. GFX:N
AGP:N
PCI-E / PCI:1*PCI-Ex16, 2*PCI-Ex1,3*PCI
USB:8 USB 2.0/ 1.1 ports (4 ports by optional cable)
LAN:VIA 10/100 Ethernet
Sound:8 Channel HD Audio
South Bridge Speed :ATA 100
RAID:N
Serial ATA:4 Serial ATA150 Channels
IEEE 1394:N
BIOS Mirror:N
Voice Genies:N

Features:

Intel Pentium® Processor (Prescott)
Socket 478 with FSB 533/800 MHz
4 DDR 333/400 Memory Sockets ( Dual Channel)
1*PCI Express x 16, 2*PCI Express x 1 , 3*PCI Slots
8 Channel HD Audio,VIA 10/100 Mbits Ethernet LAN
4 Serial ATA150 Channels,
8 USB 2.0/1.1 Ports (4 ports by optional cable)

Processor

Intel Pentium® Processor (Prescott)

FSB

533/800 MHz

Chipset

North Bridge : Intel 915P (Grantsdale P)
South Bridge : Intel ICH6
LAN Chip : VIA VT6105 10/100 Ethernet LAN
HD Audio Codec : Realtek ALC880
I/O Chip: Winbond Smart I/O W83627THF

Memory

4 * DDR Sockets:
DDR333/400 NON-ECC DDR SDRAM up to 4GB

Expansion Slots

1 x PCI Express x 16
2 x PCI Express x 1
3 x PCI slots (PCI 2.3 compliant

IDE / SATA Connectors

1* ATA100 Channel, up to 2 ATA 100 IDE devices

Onboard I/O Connectors

1 x Floppy Connector
2 x USB 2.0/1.1 header (4 ports by optional cable)
1 x CD_IN header
1 x S/PDIF in/out header (S/PDIF in/out cable optional)
1 x CPU fan header ( 1 fan rotation detection function )
2 x System fan headers ( 2 fan rotation detection function )
1 x 10 pin system panel header (Intel spec)
1 x 3 pin Power LED header
1 x Front audio header (Intel spec)
1 x IrDA header
1 x Case Open detection header

I/O via Back Panel

PS/2 keyboard/mouse, 4 x USB(2.0/1.1), 1 x RJ45 , 1 x Com(serial), 1 x Parallel, 1xLine-in/Line-out(Speaker Out)/MIC/SUR_CEN/SUR/R:WOF,L:CEN

Power

24-pin ATX power connector, 4-pin ATX 12V power connector

BIOS Feature

4Mb Flash EEPROM
Award BIOS with ACPI, DMI2.0, PnP, WfM2.0, Green Suspend to RAM (S3), Suspend to Disk (S4) Wake on keyboard/mouse, Wake on LAN/RTC Timer

Hardware Monitoring

3 FAN sensors, CPU/System voltages and temperature monitoring

Special Feature

Zero Jumper Design
Adjustable CPU frequency by 1 MHz increment, Adjustable Vcore, VAGP, VMemory for overclocking
Watch Dog Timer (auto-reset system when it can not handle overclock configurations
