Intelligent Data Protection
Highly advanced Intel® Matrix Storage technology allows RAID 0 (Striping), RAID 1 (Mirroring), RAID 0+1 (Striping and Mirroring), and RAID 5 (Parity RAID) multi-disk designs to be created by the user depending on their preference for protection or performance.
Step on to high speed connectivity
The high-speed Gigabit Ethernet for LAN connection speed of up to 1,000 Mb/s, allows internet activities such as online gaming or watching streaming videos without delays. As well the onboard Firewire (IEEE1394b) delivers high-speed data thru-put of up to 800Mb/s, enhances PC connectivity for consumer electronics A/V appliances, storage peripherals and portable devices.
CPU Intelligent Accelerator 2
With GIGABTYE C.I.A 2 technology, users are able to enjoy the benefits of overclocking without having too much trouble of manually adjustment. C.I.A. 2 provides reasonable and acceptable overclocking options for user to select, all what user need to do is to select the desirable overclocking level and the rest environment settings are automatically setup by the BIOS.
Memory Intelligent Booster 2
Designed to maximize memory performance and boost memory bandwidth by optimizing data transmission among CPU, north bridge chipset and memory. The innovative GIGABYTE M.I.B. 2 technology shortens memory latency time and enhances system performance without sacrificing stability.
Intel® High Definition Audio
Intel® High Definition Audio enables premium digital sound in the PC for an immersive surround sound experience. In addition, Intel® HD Audio delivers multiple audio channels in your PC so you can listen to two different streams simultaneously in two separate rooms.
Specifications:
Processor
1. LGA775
2. Intel® Pentium® D Processor
3. Intel® Pentium® 4 Processor
4. Supports 1066/800/533MHz FSB
Chipset
1. Northbridge: Intel® 945P Express Chipset
2. Southbridge: Intel® ICH7R
3. T.I IEEE1394b controller
4. GigaRAID ITE8212 IDE RAID controller
5. Broadcom 5789 Gigabit Ethernet controller
6. Realtek ALC882 audio codec
Memory
1. 4 DDR II DIMM memory slots (supports up to 4GB memory)
2. Supports 1.8V DDR II DIMM
3. Supports dual channel DDR II 667/533/400 DIMM
Internal I/O Connectors
1. 4 x Serial ATA II 3.0Gb/s connectors
2. 1 x UDMA ATA 100/66/33 connectors
3. 2 x UDMA ATA 133/100/66 connectors
4. 1 x FDD connector
5. 2 x IEEE1394b connectors (supports 3 ports)
6. 2 x USB 2.0/1.1 connector (supports 4 ports)
7. 3 x Cooling fan pin headers
8. 1 x Game/Midi connector
Expansion Slots
1. 1 PCI Express x 16 slot
2. 2 PCI Express x 1 slots
3. 3 PCI slots
Rear Panel I/O
1. 4 x USB 2.0/1.1 ports
2. 1 x RJ45 ports
3. 6 x Audio ports (4 x Line-out/ 1 x Line-in/ 1 x MIC)
4. 1 x Coaxial S/P-DIF out
5. 1 x Optical S/P-DIF out
6. PS/2 Keyboard/ Mouse
7. 1 x COM port connector
8. 1 x LPT port
Form Factor
1. ATX form factor; 30.5cm x 22.0cm
