Processor Supported
* Supports Dual AMD® Opteron Processor
* 800MHz Hyper Transport bus

ChipSet Description
* AMD® 8111
* AMD® 8131

System Memory
* Supports 4 * DDR socket slots for Primary CPU
* Supports 4 * DDR socket slots for Secondary CPU
* CPU1 supports memory capacity up to 8GB
* CPU2 supports memory capacity up to 16GB
* Supports registered ECC and DDR200/266/333/400

System BIOS
* Phoenix BIOS on 4Mbit Flash RAM
* Supports PXE
* Multiple boot options
* DMI 2.0 compliant
* Supports Console Redirection

Integrated Video Controller
* Build in ATI® Rage XL with 8M SDRAM on board

Integrated IDE / SCSI Controller
* Adaptec® 7902W U320 SCSI Controller

Support RAID Function
* Support RAID 0,1

Integrated Network
* Intel®82545GM Gigabit Ethernet controller
* Intel®82541GI Gigabit Ethernet controller
* Wake On LAN (WOL)
* Adapter Fault Tolerance (AFT)
* Adaptive Load Balancing (ALB)
* EtherChannel* (FEC/GEC)

Integrated Super I/O Controller
* ITE® IT8712F

I/O Connectors
* 2 x PS/2 (Keyboard and Mouse Connectors)
* 2 x USB 1.1
* 1 x COM
* 1 x LPT
* 2 x LAN RJ45
* 1 x VGA

Expansion Slot
* 4 x PCI-X 64bit/66~100MHz Slots
* 2 x PCI 32bit/33MHz slots

Board Dimension
* EATX Form Factor
* 12"W x 13"D
