Intel NUC BOXNUC7PJYH4 JUNE CANYON Pentium J5005 1.50 GHz UHD Graphics 605

Sorry, this product is not currently available to order

Here are some other products you might consider...

Intel NUC BOXNUC7PJYH4 JUNE CANYON Pentium J5005 1.50 GHz UHD Graphics 605

With HDD Support

Customer rating

Click to share your rating 0 ratings (0.0/5.0 average) Thanks for your vote!

Share this product

Unavailable
Sorry, this product is not currently available to order

Description

INTEL NUC BOXNUC7PJYH4 INTEL JUNE CANYON PENTIUM J5005 1.50 GHz UHD GRAPHICS 605

Product Collection
Intel® NUC Kit with Intel® Pentium® Processors

Board Form Factor
UCFF (4" x 4")

Socket
Soldered-down BGA

Internal Drive Form Factor
2.5" Drive

# of Internal Drives Supported
1

Lithography
14 nm

TDP10 W

DC Input Voltage Supported
12–19 VDC

Processor Included
Intel® Pentium® Silver Processor J5005 (4M Cache, up to 2.80 GHz)

Warranty Period
3 yrs

Max Memory Size (dependent on memory type)
8 GB

Memory Types
DDR4–2400 1.2V SO-DIMM

Max # of Memory Channels
2

Max Memory Bandwidth
38.4 GB/s

Max # of DIMMs
2

ECC Memory Supported ‡
No

Integrated Graphics ‡
Yes

Graphics Output
2× HDMI 2.0a

# of Displays Supported ‡
2

Removable Memory Card Slot
SDXC with UHS-I support

# of USB Ports
6

USB Configuration
2× front and 2× rear USB 3.0; 2× USB 2.0 via internal headers

USB Revision
2.0, 3.0

USB 2.0 Configuration (External + Internal)
0 + 2

USB 3.0 Configuration (External + Internal)
2B 2F + 0

Total # of SATA Ports
1

Max # of SATA 6.0 Gb/s Ports
1

RAID Configuration
N/A

Audio (back channel + front channel)
7.1 digital; L+R+mic (F); L+R+TOSLINK ®

Integrated LAN
10/100/1000

Integrated Wireless‡
Intel® Wireless-AC 9462

Integrated Bluetooth
Yes

Consumer Infrared Rx Sensor
Yes

S/PDIF Out Connector
TOSLINK

Release date Australia
July 13th, 2018
Manufacturer code:
BOXNUC7PJYH4
Brand
Manufacturer
Box Dimensions (mm)
140x125x114
UPC
735858365147
Product ID
28252918
