Practical Oscillator Circuits by Andy Flind
Sorry, this product is not currently available to order


One of the most frequently use electronic "building blocks" is the oscillator, and the aim of this book is to provide a rich source of these for enthusiasts to experiment with and perhaps use in their own designs. Extensive coverage is given to circuits using capacitors and resistors of control frequency. designs using CMOS, timer ICs and op-amps are all described in detail, with a special chapter on "waveform generator" ICs. Reliable "white" and "pink" noise generator circuits are also included. Various circuits using inductors and capacitors are covered, with emphasis on stable low frequency generation. Some of these are amazingly simple, but are still very useful signal sources. Crystal oscillators have their own chapter. Many of the circuits shown use readily available special ICs for simplicity and reliability, and offer several output frequencies. Finally, complete constructional details are given for an audio, sinewave generator, which will prove to be a most useful piece of test instrument for any enthusiast's workshop.

Table of Contents

Timer based oscillators; Cmos resistor capacitor oscillators; Op-AMP resistor capacitor oscillator; waveform generator IC oscillators; inductor capacitor oscillators; crystal oscillators circuits; practical construction methods.
Release date Australia
May 1st, 1996
Country of Publication
United Kingdom
Bernard Babani Publishing
Product ID
